Accuenergy – AcuMesh – Wireless Modbus-RTU Transceiver

SKU: AcuMesh-L-900

The AcuMesh wireless RS485 solution is designed to deliver wireless communications to energy meters or other devices that use Modbus-RTU over RS845. AcuMesh eliminates the need for the installation of traditional, hard-wired communication lines, saving money, time, and labour while also reducing the challenges of retrofit installations.

Create a Wireless Mesh Network using existing Modbus-RTU devices. Designed for Modbus-RTU devices with an RS485 port, multiple AcuMesh wireless Modbus-RTU transceivers form a point-to-multipoint wireless mesh network that monitors energy flow, industrial processes, HVAC, security systems, or other services across commercial and industrial facilities where physical wire installation is impractical. Used in new or retrofit applications, AcuMesh can reduce high installation cost.

Key features:

Compatible with Modbus-RTU protocol
Creates a wireless mesh network
Connects to meters, sensors, or any other device with an RS485 port
Mesh structure enables robust, wireless Modbus-RTU communications
Wide range: 1000ft (305m) / 4 miles (6.5km) outdoors in a single hop
Communication pathway is automatically optimized to create a superior, wireless network
AcuMesh transceivers automatically connect to each other without any special configuration
128-bit Advanced Encryption Standard (AES) provides added security
Advanced configuration options available for complex networks using free, easy-to-use software
Available in both 900MHz or 868MHz frequency for worldwide compatibility

Part Number	AcuMesh-L-900
Compatible Countries/Regions	North and South America, Oceania, part of Asia, International Telecommunication Union Region 2 and 3
Connection	RS485 screw terminal, USB mini-B (power supply and/or configuration)
Serial Baud Rate Range	9600 – 230400
RF Properties
Operating Frequency Band	902 to 928 MHz (900 Mhz ISM Band)
Number of Channels	64
Spread Spectrum	Frequency Hopping
Transmit Power Output	24 dBm (250 mW)
Receiver Sensitivity	-101 dBm
Indoor/Urban Range	Up to 1000′ (305 m)
Outdoor RF Line-of-Sight Range	Up to 4 miles (6.5 km) with 2.1 dBi dipole antennas
RF Data Rate	Up to 200 kb/s
Antenna
Impedance	50 ohms unbalanced
Networking and Security
Supported Network Topologies	Mesh, point-to-point, point-to-multipoint, peer-to-peer
Addressing Options	Personal Area Network Identifier (PAN ID) and 64-bit MAC addresses
Encryption	128 bit Encryption Standard (AES)
Power Requirements	Power supply included in kit
Power Supply	24VDC DIN-Rail Mount
Power Supply Range	7-30VDC power
Receive Current	0.54mA
Transmit Current	1.26mA
Physical Properties
Size	3.54 x 2.1 x 1.26 inch (9 x 5.3 x 3.2 cm)
Weight	80g
Mounting	DIN-Rail or Wall Mount
Includes	Transceiver, Antenna, Power supply
Certification	United States (FCC Part 15.247) Industry Canada (IC) Australia C-Tick
