Kinco - G2156E2 Green Series HMI
Kinco - G2156E2 Green Series HMI - Image 2

Kinco – G2156E2 Green Series HMI

SKU: G2156E2

  • 15.6″, 2K display, 16.00M true color;
  • Designed with single Ethernet port and dual serial ports, achieve worry-free communication;
  • Quad-core CPU + 512M memory + 4GB flash memory, extreme performance;
  • Metallic shell + three-proofing coating + power isolation, safe and reliable;
  • With the latest configuration software Kinco DToolsPro;
The G2156E2 is a robust 15.6-inch Full HD Human Machine Interface (HMI) designed for demanding industrial environments. It features a responsive 4-wire resistive touch panel, powered by a Quad-core ARM 1.5GHz processor with 4GB flash and 512MB memory. Offering versatile connectivity including Ethernet, USB, and multiple serial ports (RS232/RS485/RS422), this HMI ensures seamless integration. Its durable metallic shell, IP65 compliant front panel, and wide operating temperature range make it a reliable choice for various control and visualization tasks.
Model/Specification G2156E2
Performance specifications
Display size 15.6″TFT
Display area 344.16(W)x193.59(H)
Resolution 1,920*1,080 pixels
Display color 16.7M
Display angle of view 80/80/80/80 (left/right/up/down)
Contrast ratio 1000:1
Backlight LED
Brightness 250cd/m2
Backlight life >20,000 hours
Touch panel 4-wire precision resistance network (surface hardness: 3H)
Processor Quad-core ARM 1.5GHz
Storage 4GB flash memory + 512MB memory
RTC Built-in RTC + 512KB recipe
Expandable storage 1USB Host
Print port USB host/serial port
Ethernet LAN0:10/100 Mbps
Program download Ethernet port/USB Slave/U disk
Communication port COM0:RS232/RS485/RS422;COM2:RS232;
Electrical specifications
Input power supply DC18V~DC28V, built-in isolated
Power consumption 15W@DC24V
Allowable loss of power <3ms
Insulation resistance Over 50MΩ@500V DC
Hi-pot test 500 VAC 1 minute
Structure specifications
Shell material Metallic
Shape size 395x259x25.5mm
Cutout size 381.5×245.5mm
Installation Buckle mounting, and VESA rack mounting (VESA 100*100mm)
Weight 2.5kg
Environmental specifications
Operating ambient temperature 0~50°C
Operating ambient humidity 10~90% RH (noncondensing)
Storage ambient temperature -20~60°C
Storage ambient humidity 10~90% RH (noncondensing)
Shockproof performance 10~500Hz, 30m/S2, X, Y, Z directions/hour
Cooling mode Natural air cooling
Product certification
Panel protection grade Ip65 compliant (4208-93)
CE authentication CE compliant (EN IEC 61000-6-4:2019, EN IEC 61000-6-2:2019)
Software
Configuration software Kinco DToolsPro
